Technical Data
IR resolution(Pixels): 256×192
Pixel size: 12µm
Frame rate: ≤25Hz
Thermal sensitivity(NETD): ≤50mK @25℃
Focus: Manual Focus
Lens size: 21.5mm
Lens focal length: 4.0mm
Field of view(FOV): 44.92°(H) × 33.42°(V)
Measurement modes: Industry & EST screening
Temperature measurement range: -20℃~450℃
Accuracy: Industry: ±2℃ or ±2% whichever is greater (0℃~450℃)
EST: ±0.5℃ (30℃~40℃)
Functions
Color palettes: Ironbow, White Hot, Black Hot, Red Hot, Lava, Rainbow, Rainbow HC
On screen analyzer: 3 Points/3 Lines/3 Rectangles
Isotherm: Auto/Below/Above/Section/Manual
Hi/Lo temperature alarm: LCD animation & Buzzer
Hi/Lo temperature tracking: √
Video recording: √
General Characteristics
USB: Type-C
Image storage format: JPEG
Video storage format: MP4
Certificates: CE, UKCA, FCC, RoHS
Languages: ZH, EN, FR, DE, IT, ES, SV
Weight: Approx. 30g
Dimension: 29.5mm×24.5mm×29.5mm
Standard accessories: Type-C extension cable, Hand Strap, Cleaning Cloth,, Cloth Bag, English manual, Documents Download Operation Guide
