Technical Data
Display: 3.5″ IPS Touch (640×480)
IR resolution(Pixels): 320×240
Spectral range: 8~14µm
Pixel size: 12µm
Frame rate: ≤9Hz
Thermal sensitivity(NETD): ≤65mK
Focus: Focus Free
Field of view(FOV): 56°(H) × 42°(V)
Temperature measurement range: -40℃~400℃
Accuracy: ±2℃ or ±2% whichever is greater
Functions
Color palettes: White Hot, Black Hot, Red Hot, Ironbow, Rainbow HC, Rainbow, Lava
Image modes: Thermal, Visual image, Fusion (T-Mix), PIP
On screen analyzer: 5 Points/1 Line/3 Rectangles/3 Circles
Isotherm: Auto/Manual
Hi/Lo temperature alarm: LCD animation, LED flashlight, Buzzer
Hi/Lo temperature tracking: √
Digital camera resolution: 5MP
Digital zoom: 2x, 4x
Video recording: √
Voice recording: √
Wi-Fi: √
Wi-Fi live streaming: √
LED lighting: √
Laser pointer: √
Laser distance measurement: √
Analysis software: PC+APP
General Characteristics
Battery: 5200mAh detachable Li-ion battery pack (UT-M17)
Operating time: ≥4 hours (with Wi-Fi off)
USB: Type-C
Storage: 32GB Micro SD card
Image storage format: JPG
Video storage format: AVI
Protection: IP54 & 2m drop proof
Certificates: CE, UKCA, FCC, RoHS
Languages: EN, FR, DE, IT, ES, SV, PL, CZ
Weight: 654g
Dimension: 260mm×97mm×99mm
Standard accessories: Type-C USB cable, Micro SD card, Li-ion battery pack×2, Quick Start Guide, Documents Download Operation Guide
