Sensor: Uncooled focal plane
Temperature range: 30˚C~45˚C
Resolution: 0.1˚C
Accuracy: ±0.5˚C (@25˚C ambient temperature)
Minimum measuring distance: 1m
Temperature measurement response time: ≤500ms (95% of reading)
Pixel of thermal imagery: 4800 (80×60)
Pixel dimemsions: 17μm
Swatches: White hot, red hot, ice blue, rainbow, iron
Bandwidth of infraed spectroscopy: 8~14μm
Field of view (FOV): 51°(H) × 38°(V)
Instantaneous field of view (IFOV): 11mrad
Thermal imaging sensitivity: ＜150mk
Frame rate: ＜9Hz
Temperature display: Center temperature measurement and high temperature tracking (default)
Image format: BMP
Image modes: Thermal image
Display resolution: 320×240
PC analysis software (PC): √
Data communication: Type-C USB
Auto power off: Selectable (5min, 10min, 30min), 30min auto power off (default)
Battery life: ≧6 hours
Charging time: 4 hours
Image storage: Micro SD card
Power: A single Li-ion 3.7V/5000mAh 26650 battery
Display: 2.8" TFT LCD
Product color: Red & grey
Product size: 236mm x 75.5mm x 86mm
Standard accessories: Manual, Type-C USB cable, 16GB TF card
