Sensor: Linear CCD sensor
Scan Rate: 200 scans/second ±10%
Pitch Angle: Forward & backward ±10°~30° (±5°) Left & Right ± 60° (±5°)
Print Contrast: 45%
Depth of Field: Field width: 80mm Reading distance: Up to 90mm @ 20mil, PCS90%, Code39
Connection Port: USB / RS232
Dimensions: 87.8 L x 71.6 W x 177.7 H (mm)
Weight: 165g without cable
Barcode Reading: 1D
Operating Voltage: 4 VDC to 5.5 VDC
Current Consumption: Operating: 252mA Standby: 77mA
Mechanical Shock: 1.5m
Operating Temperature: 0°C to 45°C (32°F to 113°F)
Storage Temperature: -20°C to 60°C ( -4°F to 140°F)
Humidity: 5% to 85% relative humidity, non-condensing
Standard: IP42
Accessories (Optional):
■ Standard hands-free stand (Optional)
■ Auto-sensing hands-free stand (Optional)
Certifications: CE, FCC, BSMI, VCCI
Optical Resolution: 3 mil (0.076mm) @ PCS90%
Communication: Wired
Button Life: 10 million times
Indicators: Beeper, LED light
