Sensor: Linear CMOS
Aiming Element: Visible red LED 625nm
Optical Resolution: 4 mil/ 0.1mm 140mm (13Mil Code 39)
Depth of Field:
4 Mil Code 39: 40 ~ 65 mm
5 Mil Code 39: 35 ~ 90 mm
10 Mil Code 39: 35 ~ 195 mm
15 Mil Code 39: 50 ~ 280 mm
13 Mil UPC/EAN: 35 ~ 230 mm
Communication: Bluetooth 2.1+EDR
Dimensions: H20W30L72mm
Weight: 30.2g
Barcodes: 1D
Operating Voltage: 3.7VDC ± 5% 6000 scans (1 scan/ 5 seconds, PAN connected)
Current Consumption: Operating Mode: < 500uA (MS912+)
ESD Protection: Functions after 4KV contact, 8KV air discharge
Mechanical Shock: 1.5m
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 60°C
Certifications: EMC: FCC Part15C, CE Safety Approvals: WEEE, RoHS 2.0, IEC 62471, NCC, TELEC, VCCI, BSMI
Memory: 2MB
Interface: BT HID, BT SPP, USB HID, USB VCP, Memory (MS912M+)
Battery Type: Lithium Battery 3.7V, 350mAh
Operating Time: 6000 scans
Scan Rate: 650 scans/second
Wireless Coverage: 10m (line of sight)
