- Relative Humidity:
Measurement range: 0 ... 100 %RH
Stability: ±0.5 %RH/year in typical HVAC applications
- Temperature:
Measurement range: -40 ... +80 °C (-40 ... +176 °F)
Default analog output scale: -20 … +80 °C (-4 … +176 °F)
Accuracy at +20 °C (+68 °F): ±0.1 °C (0.18 °F)
Temperature dependence: ±0.005 °C/°C
Factory calibration uncertainty: ±0.1 °C (0.18 °F)
- Analog output:
Accuracy at +20 °C (68 °F): : ±5 mV
Temperature dependence: ±0.2 mV/°C
- Power supply input: 15 … 35 VDC/16 … 24 VAC
- Power consumption: 1.0 W (typical, for both AC and DC)
- Analog outputs: 1 × RH output 0 … 10 V, 1 × T output 0 … 10 V (load resistance: 10 kΩ min.
- Digital output (RS-485): Isolated, supports Modbus RTU and BACnet MS/TP protocols
- IP rating: IP66 (NEMA 4X)
- Weight: 511 g (18 oz)
