Cable Length Measurement 2-400m:
Resolution: -
Best Accuracy: -
Cable Length Measurement 2-600m:
Resolution : 0.1m
Best Accuracy : ±(1%+5)
Intelligent Wiremap:
Shorts: Yes
Split Pair: Yes
Breakpoint checking: Yes
Length of Network Cable (8P8C): Yes
Length of Network Cable (4P4C): Yes
Length of Phone Cable: Yes
Length of BNC Cable: Yes
Analogue Cable Tracing: Yes
Digitalized Cable Tracing:
Port Blink Test: Yes
Voltage Measurement (via network cable jack for reference): Yes
PoE Voltage Polarity Checking: Yes
POE Voltage measurement (for reference only): Yes
Continuity (via network cable jack): Yes
PoE Voltage Protection: Yes
Vibration inducation: Yes
Remote Identification (Optional): 7
User Calibratable: Yes
User Calibration Result Storage: Yes
Multimeter:
DC Voltage 400mV-600V : ±(0.8%+3)
AC Voltage 4V-400V: ±(1.5%+5)
DC Current 1A-10A : ±(1.2%+4)
AC Current 1A-10A : ±(2%+5)
Resistance 200Ω-20MΩ : ±(2%+6)
Diode: P
Continuity: P
Temperature: ±(2%+15)
Max Display : 9999
Display Backlight: Yes
Flashlight: Yes
Sensitivity adjustable: Yes
Low Power indication: Yes
Auto Power off: Yes
Power By : Main Body: 3.7V, 1250mAH Lithium Ion Battery; Receiver: 9V (6F22)
