Direct access to our certified experts
Analogue Cable Tracing: Yes
Digitalized Cable Tracing: Yes
Tracing cables connected to ethernet hub with POE support: Yes
Port Blink Test: Yes
Identify wire Pairs and quality of wire connections: Yes
Voltage Measurement (via network cable jack for reference): Yes
POE (Standard) Voltage Polarity Checking: Yes
POE (Non Standard) Voltage Polarity Checking: Yes
POE (Standard) Voltage measurement (for reference only): Yes
POE (Non-standard) Voltage measurement (for reference only): Yes
Crimping Crystal Test: Yes
Continuity (via network cable jack): Yes
Intelligent Wiremap: Yes
Shorts: Yes
Split Pair: Yes
Continuity Test: Yes
NCV: Yes
Analogue Bargraph: Yes
Tracing signal transmission distance : 3km
Output signal level : ~15Vp-p
Vibration inducation: -
Flashlight (both main body & transmitter): Yes
Loudness Adjustable: Yes
Sensitivity Adjustable: Yes
White Display Backlight: Yes
Low Battery Indication: Yes
Auto Power Off: Yes
Working on Network Cable (8P8C, 4P4C), Phone Line and Coaxial Cable: Yes
Cable Length Measurement:
Length : -
Resolution: -
Best Accuracy: -
User Calibration:
Multimeter:
DC Voltage 400mV~250V: -
AC Voltage 4V~250V : -
DC Current 1A~10A: -
AC Current 1A~10A : -
Resistance 200Ω~20MΩ : -
Diode: -
Temperature -20~1000°C : -
Input Jack Indicators: -
Power by Transmitter : : 3.7V, 1250mAH Rechargable Lithium Battery
Power by Receiver : : 9V (6F22)
