Main Body :
Bipolar Live Wire Tracing: Yes
Unipolar Live Wire Tracing: Yes
Non-powered Wire Tracing: Yes
Digitalized Wire Tracing: -
Cable Layout Checking: Yes
Pipe Locator: Yes
Cable Break Point Checking: Yes
Cable Shorting Point Locator: Yes
Signal Output 125kHz; Code: A/C/E/F/H; Level : 4: Yes
Voltage Test (by using Cable Clamps): Yes
DC Voltage Range 10~400V: ±0.8%
AC Voltage Range 10~400V (50~400Hz): ±1%
Tracing signal transmission distance : 3Km
Sensitivity Adjustable: Yes
Flashlight: Yes
Low Battery Indication: Yes
Multimeter:
DC Voltage 600mV~1000V: ±(0.5%+0.3)
AC Voltage 600mV~750V: ±(0.8%+0.5)
DC Current 600mA~10A: ±(1%+0.4)
AC Current 600mA~10A: ±(1%+0.5)
Resistance 600Ω~60MΩ: ±(1%+0.6)
Frequency 6Hz~6MHz: ±(2%+0.6)
Capacitance 6nF~60MF: ±(1%+0.1)
Diode: Yes
Continuity: Yes
Input Jack Indicators: Yes
Display Counts: 60000
Auto Power Off: Yes
Display Mode Main Body : 320x240 Color Dot Matrix LCD
Power by. : 3.7V 1500mA Lithium ion
Receiver :
Tracing Depth (Cable Locator Mode)*:
Bipolar app. 0~0.5m: Yes
Unipolar app. 0~2m: Yes
Voltage Test App. 0~0.4m: Yes
Display Information from Transmitter: Transmission code, level, direction and signal intensity: Yes
Display Mode : Vertical Alignment
Auto Power Off: Yes
Power by 3.7V 1500mA Lithium ion: Yes
