Detector type: Filtered InGaAs
Optical interface/connectors: Universal 2.5 mm/1.25 mm1
Wavelength range: 780 to 1650 nm
Wavelength settings: 780 to 1650 nm, step size 1 nm
Programmable wavelengths: 5 presets (customized)
Calibrated wavelengths: 850, 980, 1310, 1490, 1550, 1625 nm
Power range: –50 to +26 dBm
Display range: –50 to +26 dBm
Max. input power: +27 dBm
Measurement units: dB/dBm/W
Intrinsic uncertainty: ±0.2 dB (±5%)
Linearity: ±0.06 dB (–32 to +20 dBm)
Tone detection: 270 Hz, 1 kHz, 2 kHz
Auto λ mode: Yes
Multi λ mode: TwinTest/serial TripleTest
Power Supply
Dry batteries: 2x Mignon (AA) 1.5 V
Rechargeable batteries: 2x Mignon (AA) NiMH 1.2 V
AC operation Via micro USB and SNT-505
Dimensions (H x W x D): 30 x 80 x 150 mm (1.2 x 3.1 x 5.9 in)
Weight: 200 g (0.45 lb)
