Bandwidth:70 MHz
Channel: 2
Sampling method:Normal, peak sampling
Real time sampling rate: 125 MSa/s(Dual channel), 250 MSa/s(single channel)
Record length:Maximum 8K for single channel, 4K for dual channel
Waveform refresh rate:10,000 wfms/s
Input coupling:DC, AC, grounding
Input impedance (DC coupling): 1M Ω ± 2%, parallel to 16pF ± 10 pF
Probe attenuation coefficient:1x, 10x, 100x, 1000X
Maximum input voltage:400V (DC+AC peak value)
Time base range:5ns/div-1000s/div, Step by 1-2-5
Vertical sensitivity:10mV/div～10V/div
Vertical resolution: 8bit
