Infrared Resolution: 120 × 90
Super Resolution: Not supported
Working Wavelength: 8–14 μm
Frame Rate: 25 Hz
Thermal Sensitivity (NETD): 60 mK @ 25°C
Field of View (FOV): 38° × 50°
Lens: 2.3 mm F1.1
Temperature Measurement Range: -20°C~400°C
Measurement Accuracy: ±3°C or ±3% of reading
Emissivity: Adjustable from 0.01 to 1.00
Measurement Modes:
Full-screen max/min/center point
Area-based temperature measurement
Color Palettes
Iron Red
White Hot
Black Hot
Rainbow
Red hot
High Contrast
Green Hot
Lava
Visible Light Imaging: Not supported
Storage & Formats
Internal Storage: 8GB (stores approx. 20,000 images)
Image Format: JPG
Video Format: MP4
General Specifications
Supported Languages: Simplified Chinese, Traditional Chinese, English, French, German, Spanish, Dutch, Japanese, Korean, Arabic
Battery: Built-in 2600mAh rechargeable battery
Display Size: 2.8 inches
Device Color: Black
Weight: 260g
Dimensions: 70mm × 80mm × 200mm
Standard Accessories: USB Type-C cable, standard charger, lanyard, user manual
