Voltage output: 0-30V
Maximum current output: 3A
Output voltage channel: 3 channels (the voltage output of the third channel is fixed at 5V, and the current output is 1A)
Series: 60V/5A Parallel: 30V/10A
Voltage stabilization feature
Output voltage: Continuously adjustable from 0 to rated voltage
Source effect: ≤1×10ˉ4+3mV(±10% of rated source voltage)
Load effect
≤1×10ˉ4+3mV (output current≤3A)
≤3×10ˉ4+3mV (output current≥3A)
Ripple and Noise: ≤1mVrms (5Hz-1MHz)
Recovery Time: ≤100μS (50% load change, Minimum load 0.5A)
Temperature drift: ≤300ppm/°C
Current stabilization feature
Output current: Continuously adjustable from 0 to rated current
Source effect: ≤2×10-3 +3mA
Load effect: ≤2×10-3 +3mA
Ripple and Noise: ≤3mArms
Tracking feature
Series feature
Source effect:≤1×10ˉ4+5mV
load effect:≤300mV
Parallel feature
Source effect:≤1×10ˉ4+3mV
Load effect:≤1×10ˉ4+3mV (output current≤3A)
Display feature
Voltage: Two sets 3-digit voltage LED display, the display accuracy: ± (0.5% + 2 words)
Current: Two sets 3-digit current LED display, the display accuracy: ± (0.5% + 2 words)
Size: 300*250*145mm
Weight: 6900g
Power: AC220V/AC110V土10%,50Hz/60Hz
