Testing frequency: 100Hz-100KHz adjustable, step from 1Hz
Basic accuracy: 0.2%
Electrolytic capacitor mode: √
DCR mode: √
Bias Voltage: 0-500mV can be adjustable, step from 1mV
Electric level: 0-0.7 adjustable
Screen: 2.8 inches TET LCD
Digits display: Main parameter: 5 digits; auxiliary parameter: 5 digits
Measuring parameters
Main parameter: L/C/R/Z
Auxiliary parameter: X/D/Q/θ/ESR
Measuring Range (L): 0-2000H
Measuring Range (C): 0-20mF
Measuring Range (R): 0-20MΩ
Measuring speed: 1 time/s (slow), 2 times/s (moderate), 4 times/s (fast)
Calibration function: Open circuit calibration, short circuit calibration
Filtering function: Limit scope 1%~50% can be set; 1%, 5%, 10%, 20% are the fix points
errors measurement: is use for comparing the percent errors between components and nominal value, meanwhile display
others: Backlight luminance can be adjustable; USB device and auto power off can be set
Standard Accessories: Mini-USB cable; power adapter; short-circuit plate; plug made of red and black rubber; Lithium battery with large capacity
