Range: AC 0.0mA～3200A
Resolution: AC 0.1mA
Measurement Accuracy (23℃±3℃, below 70%RH, measured wire at the center of the clamp) AC 0.0mA～499A ±2%±5dgt
AC 500A～999A ±3%±5dgt
AC 1000A～2999A ±4%±5dgt
AC 3000A～4000A ±5%±5dgt
Power: 6V DC(LR6×4 alkaline dry batteries, continuously working for 12 hours)
Weight of Meter: 1.5kg (with batteries)
Dimension: Length 350mm* width 180mm * thickness 55mm
Clamp Size: 108mm×148mm (can clamp electric cable of 108mm diameter, or 160mm×4mm flat cable and steel earth wires)
Sample Rate: About 2 times/second
Frequency: 50Hz ,60Hz automatic identification
Communication Wire: RS232 communication wire, 1.8m
Data Storage: 99 sets, “FULL” symbol indicate the memory is full
Data Hold: “HOLD” symbol appears
Overflow: “OL” symbol appears
