VICTOR 8246B Bench-type DMM (1000VDC, 750VAC, 10ACA/DCA, TRMS, 1kHz)

DC voltage: 50mV/500mV/5V/50V/500V/1000V ±(0.025%+5dgt)

AC voltage: 50mV/500mV/5V/50V/500V/750V ±(0.7%+30dgt)

DC current: 500uA/5000uA/50mA/500mA/5A/10A ±(0.15%+10dgt)

AC current: 500uA/5000uA/50mA/500mA/5A/10A ±(0.8%+30dgt)

Resistance: 500Ω/5kΩ/50kΩ/500kΩ /5MΩ/50MΩ ±(0.05%+5dgt)

Capacitance: 10nF/100nF/1000nF/10uF/100uF /1000uF/10mF/100mF ±(5%+5dgt)

Frequency: 10Hz～100kHz ±(0.02%+4dgt)

Thermocouple: K indexing:-200.0°C～1360.0°C ±(0.5%+0.5°C)

RTD: Pt100:-200.0°C～850.0°C ±(0.5%+0.5°C)

Display words: 55000

The measurement rate

Quick: 20 times / sec

Slow: 5 times / sec

Bandwidth: 1kHz
