Rated Voltage:50V, 250V, 500V, 1kV, 2.5kV, 5kV, 10kV
Insulation Resistance Range:0.005MΩ~10.0TΩ
Short Circuit Current: 5mA Max
Function:Insulation resistance measurement (IR); polarization index measurement (PI); absorption ratio (DAR); Step test(STEP); Ramp test(RAMP); Voltage measurement(V);
Power Supply:Rechargeable lithium battery 5.2Ah 14.8V
Custom Setting Voltage: 40V~5kV
Output Voltage Accuracy:(5%~10%)±10V
Polarization Index(PI):Yes
Dielectric Absorption Ratio(DAR):Yes
Step Test(STEP):Yes
Ramp Test(RAMP):Yes
Voltage Test
Range: DC:0V~800V；Accuracy: ±5%rdg±3V
Range: AC: 0V~700V; Accuracy: ±5%rdg±3V
Real Time Current Display:Display test current value, current display range: 0.001nA～5mA
Real Time Voltage Display:Real time monitoring the voltage of the tested terminal,In the non-test state, when the voltage is larger than 36V, the test is prohibited to protect the safety of the instrument and the operator.
Test Timer:Automatic record test time, time range: 0s~9999s
Test Time:After selecting the DAR, PI test options, the test will be stopped immediately after the test result is obtained; in the custom test mode, the test duration can be set by user; in the normal test mode, the test time is not limited, and the operator can manually stop the test.
Custom Setting Time:10s~3600s
Store Function:Automatically store the test data, which can reply the test record in tester
USB Communication:Yes, the test record can upload to the PC through USB cable
Bluetooth Communication:Yes, can be connected to Android phones or other devices with Bluetooth communication function.
Battery Power Display:With battery power display, when battery voltage low will remind to charge in time
Automatic Shutdown:After 15 minutes start up will shut down automatically without any operation
Tester Dimension:280mm×260mm×160mm
Tester Weight:Host: 4326g (include the battery); Total weight: 6.96kg (Accessories)
Protection Level:Close the case IP65, open the case IP40
Working Environment:-20℃～50℃；80%rh
Store Environment:-25℃～65℃；80%rh
Insulation Resistance:50MΩ(1000v)(between the test circuit and shell)
Withstand Voltage:AC 3kV 50Hz 1min(between the test circuit and shell)
Suitable Safety Standard:IEC61010-1,IEC61326-1
