Specification
DC Voltage: 400mV/4V/40V/400V/1000V ±(0.5%+4)
AC Voltage: 4V/40V/400V/750V±(0.8%+10)
DC Current: 400uA/4000uA/40mA/400mA/10A±(1%+10)
AC Current: 400uA/4000uA/40mA/400mA/10A±(1.5%+10)
Resistance: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ±(0.8%+4)
Capacitance:
10nF ±(5%+20)
100nF/1uF/10uF/100uF±(3.5%+8)
1mF/10mF/100mF±(5.0%+10)
Frequency: 100Hz/1000Hz/10kHz/100kHz/1MHz/30MHz ±(0.5%+10)
Temperature: (-20~1000)℃ /(-4-1832)℉ ±(1.0%+5)
Features
Diode √
Transistor √
Continuity buzzer √
Low battery indication √
Backlight √
Data Hold √
True RMS √
Auto power off √
Analog bar graph √
Shockproof protection √
Duty Cycle: 1%~99.%
Input impedance: 10МΩ
Sampling rate: 3 times/s
AC Frequency response: 40~400Hz
Operation way: Auto Range/Manual Range
Max. Display: 3999
LCD size: 70×50mm
