Receiver:
Sensor: CMOS (Mono, Global Shutter)
Resolution: 1408 x 1024
Focus: Manual
Maximum Frame Rate (FPS): 60
Focal Length: 6.72 mm (0.2646”)
Pixel Size: 3.45 μm x 3.45 μm
Sensor Size: 1/2.9”
Emitter: Illumination Light Source Option: High Intensity Red LED
Reading Specifications:
Supported Symbols: 2D Codes: QR Code and Data Matrix, Barcodes: Code 39, Code 93, Code 128, CodaBar, EAN8, EAN13, ITF25, ITF14, UPCA and UPCE
Minimum Resolution: 2D Codes: 0.062 mm (0.0024”), Barcodes: 0.023 mm (0.0009”)
Reading Distance: 40 mm to 120 mm (1.5748” to 4.7244”)
Reading Field of View
(Working distance at 120 mm (4.7244”)): 86.74 mm x 63.09 mm (3.4149” x 2.4838”)
Maximum Reading Speed: 45 codes/sec
I/O Specifications
Number of Control Inputs: 1
Number of Control Outputs: 1
Ethernet Supported Protocol: SmartSDK, TCP Client, Serial, FTP, TCP Server, ModBus and UDP
Serial Communication Standard: RS-232C Compliant
Environment Resistance
Enclosure Rating: IP65 *3
Surrounding Temperature: 0 to + 45 ° C (32 to 113 ° F)
Ambient Storage Temperature: -30 to + 70 ° C (-22 to 158 ° F)
Rating
Power Consumption: 3.6 W
Power Supply Voltage: 24 VDC
Current Consumption: 0.15 A
Weight: Approx. 160 g (0.3527 lb.)
Dimension (L x W x H): 46 mm x 38 mm x 25 mm (1.8110” x 1.4961” x 0.9843”)
