Width: 8.18 mm
Height: 3 mm
Length: 8.18 mm
Core Type: Molded
Shielding: Shielded
Tolerance: 20 %
Inductance: 1 uH
Application: Commercial
Termination: Standard
Unit Weight: 1.600 g
Core Material: Composite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 13.7 A
Saturation Current: 29 A
Maximum DC Resistance: 8.35 mOhms
Self Resonant Frequency: 51 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
