Width: 5.5 mm
Height: 6.15 mm
Length: 5.5 mm
Wavelength: 850 nm
Unit Weight: 505.850 mg
Dark Current: 100 nA
Light Current: 15 mA
Mounting Style: Through Hole
Peak Wavelength: 850 nm
Lens Color/Style: Clear
Pd - Power Dissipation: 250 mW
Half Intensity Angle Degrees: 10 deg
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
Maximum On-State Collector Current: 50 mA
Collector- Emitter Voltage VCEO Max: 70 V
Collector-Emitter Breakdown Voltage: 70 V
Collector-Emitter Saturation Voltage: 150 mV
