Width: 4.8 mm
Height: 6.95 mm
Length: 5 mm
Beam Angle: 45 deg
Unit Weight: 400 mg
Viewing Angle: 45 deg
Mounting Style: Through Hole
Output Current: 5 mA
Carrier Frequency: 38 kHz
Low Level Pulse Width: 0.15 ms
Transmission Distance: 45 m
High Level Pulse Width: 0.15 ms
Pd - Power Dissipation: 10 mW
Operating Supply Current: 350 uA
Operating Supply Voltage: 2.5 V to 5.5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
Minimum High Level Output Voltage: 100 mV
