Width: 3 mm
Height: 3.2 mm
Length: 6.8 mm
Beam Angle: 100 deg
Unit Weight: 200 mg
Viewing Angle: 100 deg
Mounting Style: SMD/SMT
Output Current: 5 mA
Peak Wavelength: 940 nm
Carrier Frequency: 38 kHz
Moisture Sensitive: Yes
Low Level Pulse Width: 0.8 ms
Transmission Distance: 40 m
High Level Pulse Width: 0.8 ms
Pd - Power Dissipation: 10 mW
Operating Supply Current: 700 uA
Operating Supply Voltage: 2.5 V to 5.5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 25 C
