Fall Time: 5 ns
Rise Time: 5 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 45 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 56.8 W
Vgs - Gate-Source Voltage: - 7 V, + 8 V
Typical Turn-On Delay Time: 12 ns
Typical Turn-Off Delay Time: 36 ns
Id - Continuous Drain Current: 172 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 1.3 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 1.3 V
