Dimensions W x D x H (mm): 460 x 460 x 665
Voltage: 230 V, 50/60 Hz
Noise level (distance 1 m) dB(A): < 51
Heating output: 460 VA
Fuse: T3, 15A
Weight (ca) in kg: 40
Max. capacity: 1-8 workplaces
USB: The USB port can be used to load firmware updates, run efficiency tests and log data. Do not leave the USB medium inserted for longer than 2 minutes. After this time expires, the USB module will switch off automatically.
Interface RS232 (Remote control): All system functions can be operated and remotely monitored via the RS232 port.
Pre filter: Pre filter mat class F7
Compact filter: Particle filter H13, Wide band gas filter (50 % Active carbon / 50 % Chemisorb)
Max Vacum (Pa): 3.000
Capacity m³/h: 615
Order Information: Kompaktfilter - WFE 20D, WFE 4S, ZS6V, ZS 20T,FC 800; Fine dust filter F7; Hose connector straightAccessories Volume Extraction
