Measuring Principle: Ultrasonic Attenuation and EEAM(Envelope Energy Average Method)
Measuring Range :
0 ~ 500,000mg/l (0 ~ 50%)
1,000 ~ 3,000kg/m³ (1.000 ~ 3.000g/cm³)
Resolution :
0.1% or 0.01% (Selectable),
1 kg/m3 or 0.001 g/cm3
Display : Graphic LCD
(Density, Time, Echo profile, mA, Etc.)
Accuracy :
±0.15% (±0.5% of F.S.)
±15 kg/m³, ±0.015 g/cm³
Operating Temp. : ‐20 ~ +70°C (‐4 to 158°F)
Outputs: Current output : 4 to 20mA, nom. Load 250Ω
(Load range: 100 to 750Ω)
Relay output : 1 SPDT (5A, 250VAC)
Digital output : RS232(STD.), RS485(Option)
Power Supply Standard : 100V ~ 240V AC, 50~60Hz, < 14W
Option : 24V DC
Enclosure Material : Body/Cover ‐ ABS
Dimension : 252(W) x 238(H) x 125(D)mm
Weight : 2,2 kg
IP Rating : IP67
Data Saving: Maximum 400 days (10K point)
Screen: Numeric, Data trend, Echo profile, parameter
Certificate: CE
