Maximum cutting length(interpolated inner hole 850mm): 1000mm
Cutting stroke speed: 4-25m/min
Return travel speed: 7-25m/min
Maximum weight for plug gable work: 4000kg
Main drive motor power: 37kw
Allow maximum cutting force(when the stroke speed is 16m-20m): 24500N
Table diameter: 1250mm
Maximum movement of the workbench: 1200/1100mm
Distance from the tool support surface to the front wall of the bed: 1120mm
Feed range: 0. 2-5mm/double stroke
Landscape: 0. 2-5mm/double stroke
Circumference(on the circumference of 9700): 0.4-10mm/double stroke
Distance from work surface to the lower end of the carriage: 1140mm
Workbench fast-moving longitudinal and horizontal: 500mm/min
Machine dimensions (length X width x height): 400×2830×570mm
Total machine weight(including electrical equipment): 22T
