Maximum cutting length(inserted hole 450 mm): 500mm
Table diameter: 1000mn
Worktable maximum longitudinal movement distance: 660nm
Worktable maximum lateral movement distance: 1000mm
Workbench maximum load: 2000kg
Distance from work surface to the lower end of the carnage: 740mm
Distance from the tool support surface to the front wall of the bed: 990mm
Ram adjustment distance: 430nm
Ram tilt angle (left and right direction): ±10deg
Number of ram reciprocation(minutes): 9.12.5.18.25.3650
Workable vertical and horizontal maneuvering feed rate map: 0.10.20.30.40.61.2
Working and turning maneuvering feed range(slipping once): 3’6’9’12’18’36
Maximum cutting force: 16000N
Main drive electric machine: 7.5kw, 1440rpm
Feed servo motor: 4.0kw
Cooling pump motor: 0.125kw2800r.p.m
Machine weight: 10.3T
Machine contour(length x width x height): 3480×2085×3307mm
Split package size: 3680/2260/1200/2250/1100/2250mm
