Spindle
Max. bar throught hole: Φ25mm
Spindel through diameter: Φ26mm
Max. revolving dia.: Φ300mm
Spindle center height from the ground: 930mm
Spindle speed range: 0-5000r/min
Spindle motor power: 2.2kw
Stroke
X stroke: 400mm（Diameter value）
Z stroke: 180mm
X axis servo motor power: 0.75kw
Z axis servo motor power: 0.75kw
Guideway: Linear guideway
CNC
Minimum setting unit: 0.001mm
Minimum moving unit X: 0.0005mm
Minimum moving unit Z: 0.001mm
Cutting speed: 1–4000mm/min
X rapid travel speed: 18000mm/min
Z rapid travel speed: 20000mm/min
Gang type: 6
Tool shank size: 16*16
Cutting motor power: 0.09kw
Capacity of coolant container: 120L
Motor power: 25w
Capacity: 1L
Input air pressure: 0.4–0.6Mpa
L*W*H: 1405*1050*1650
Weight: 900kg
