Max.swing over bed: Ф480mm
Max.swing over cross slide: Ф350mm
Max.maching diameter(disk/rod): Ф320mm/Ф80mm
Max.length of work piece: 420mm
spindle bearing diameter: Ф100
Spindle bore diameter: Ф62mm
Spindle bore taper: 80mm
Spindle nose: A2-6
Spindle speed range: 60-3800r/min
Power of the main motor: 7.5-11kw
Min.input unit: 0.0005/0.001mm
Rapid speed: 20/20m/min
Hydraulic chuck: 8″
Hydraulic station: 8
Max.dia for boring size: Ф32
Quill diameter: Ф80mm
Quill travel: 80mm
Packing size: 2220x1405x1640mm
N.W/G.W: 3800/4200kg
