Max dia.swing over bed (mm): 1250
Max dia.swing over cross slide (mm): 880
Max.length of work-piece (mm): 1500
Width of bed (mm): 755
Spindle bore (mm): 130
Power of spindle motor (kw): 22
Spindle front taper: 1:20/140
Range of spindle speed (r/min): 17-250
Max.traverse of X/Z (mm): X:580 Z:1500
X/Z rapid traverse (r/min): 3000/6000
X/Z axis motor speed (r/min): 1500/1500
X/Z axis motor torgue (N.m): 18/30
X/Z axis motor power (kw): 2.8/3.8
Tailstock quill diameter(mm): 160
Tailstock quill travel (mm): 300
Tailstock quill taper: Morse NO.6
Electric tool-post model: SLD170A
Electric tool-post dimension (mm): 300×300
Positioning accuracy (mm): 0.02
Overall dimensions (L*W*H)(mm): 4500*2300*2300
Machine weight (kgs): 10
