Swing over bed: 320mm
Swing over cross slide: 198mm
Swing over gap: 476mm
Distance between centers: 750/910/1000mm
Spindle bore: 38mm
Spindle taper: MT5
Spindle speed range: 65-1700rpm or 65-1810rpm
Longitudinal feed range: 0.079-10.291 mm-r, 0.003″-0.0508″ /rev
Cross feed range: 0.017-0.276 mm/rev 0.0007″-0.0108″ /rev
Metric thread range: 0.4-7mm
Inch thread range: 4-60 TPI
Travel of tailstock: 100mm
Taper of tailstock: MT3
Motor power: 1.1kw/1.5kw
G.W: 550/590/670kgs
N.W: 500/540/640kgs
Packing size: 1480/1680/1970x750x1400mm
