Max. swing over bed: 400mm
Max. swing over cross slide: 264mm
Max. swing in gap: 550mm
Center height: 200mm
Max. length of workpiece: 1000mm
Width of bed: 206mm
Max. section of cutting tool: 16x16mm
Cross slide travel: 150mm
Spinde bore: φ 51mm
Spindle taper: MT5 or MT6
Spindle nose: D4 or D5
Spindle speed: 45-1800rpm 16 steps
Threads metric pitches: 0.4-7mm/28 kinds(Metric lathe),0.45-7.5mm/22 kinds(Inch lathe)
Threads inch pitches: 4-56TPI/28 kinds(Metric lathe),4-112TPI/40 kinds (Inch lathe)
Longitudinal feeds: 0.043-0.653mm/rev (Metric lathe),0.0012-0.0297in/rev (Inch lathe)
Tailstock quill travel: 100mm
Tailstock quill diameter: 45mm
Tailstock quill taper: MT3
Coolant pump power: 40W
Main motor power: 1.5/2.4KW
Packing size: 1950x750x1500mm
N.W/G.W: 700/800kg
