Swing over bed: 1250mm
Bed width: 755mm
Workpiece length: 1500/ 3000/ 5000/ 6000/ 8000/ 15000mm
Swing over toolpost: 860mm
Max. turning length: 1300/ 2800/ 4800/5800/7800/14800mm
Toolpost feed kinds each spindle rotate: 56 kinds
Toolpost cross feed range each spindle rotate: 0.1-12mm/r
Toolpost longitudinal feed range each spindle rotate: 0.05-6mm/r
Upper toolpost: 0.025-3mm/r
Metric thread: 44 kinds 1-120mm
Inch thread: 31 kinds 28-1/4 teeth / inch
Module thread: 45kinds 0.5-60mm
Pitch thread: 38 kinds 1/2-56DP
Spindle bore: 130mm
Spindle front taper: Metric 140
Spindle speed steps and range forward: 21 kinds 3.15-315r/min
Max.section of tool: 45×45mm
Toolpost longitudinal travel: 630mm
Upper toolpost travel: 300mm
Toolpost rapid movement, Longitudinal/Cross/Upper: 3470/1870/935mm/min
Center sleeve dia and travel: 160×300mm
Tailstock taper: MT6
Tailstock longitudinal movement: ±25
Main motor: 22KW
Carriage rapid motor: 1.5KW
Coolant pump: 90W
Coolant pump flow: 45L/min
