Swing over bed: 630mm
Swing over toolpost: 350mm
Swing over gap: 1300mm
Center distance: 1000mm 1500mm 3000mm 5000mm
Spidle bore size and spindle type: φ120mm, D11
Spindle nose taper and center taper: φ140, MT5
Spindle speed kinds and range: 18 kinds, 5.4-720r/min
Longitudinal Feeding speed and range: 64 kinds 0.06-24.3mm/r
Range 1:1: 0.1-1.52mm/r
Range 16:1: 1.6–24.3mm/r
Micro feeding with change gears: 0.05-0.76mm/r
Ratio of cross feeding and longitudinal feeding: 1:02mm
Bed fast moving: 4000mm/min
Leadscrew pitch: Metric 12 inch 1/2”
Metric thread range: 50kinds 1-240mm
Inch thread range: 26 kinds 14-1t.p.i
Module thread range: 53 kinds 0.5-120mm
Pitch thread range: 24kinds 28-1mm DP
Max. travel of Upper toolpost: 315mm
Max. travel of Lower toolpost: 200mm
Tailstock travel: 250mm
Tailstock taper : MT5
Main Motor power: 11kW
Fast moving motor power: 1.1kW
Coolant pump power: 90W
Bed width: 550mm
Bed hardness: 600RC52
Max. Loading weight: 1500kg
