Grinding dia.(O.D/I.D): Φ2~Φ80/Φ10~Φ60mm
Grinding length.(O.D/I.D): 300/125mm
Center height: 115mm
Worktable speed: 0.1~4m/min
Max.travel of table: 340mm
Max.workpiece weight: 10kg
Swivel range of worktable: 3~+7°
Wheel peripheral velocity: 35m/sec
Externalwheef size: MaxΦ250×25×Φ75mm, MinΦ180×Φ75mm
Internal wheel spindie totating-speed: 16000r/min
Workhead and tailstock center: NO.3 morse
Machine motor power: 2.34kW
Overall dimensions(L×W×H): 1360×1240×1000mm
Machine weight: 1500kg
