Table maximum cutting area (LxWxH): 500x190x335mm
Working table movement:
Max. Grinding Length: 500mm
Max. Grinding width: 190mm
Distance From Table Surface To Spindle Center: 335mm
Slideway: V-type rail with Steel-ball
Maximum workload: 200kg
Table size: 460×180mm
Number of T -Slot: 14×1mmxn
Front and rear wheel feed: 0.02mm/Graduation, 2.5mm/revolution
On the hand wheel feed: 0.01mm/Graduation, 1.25mm/revolution
Wheel Size(dia×width×bore): 180×13×31.75mm
Spindle speed: 50Hz: 2850rpm
Variable frequency motor (matching): 0-6000rpm
Spindle motor: 1.1kW
Cooling pump: 0.4kW
Packing Size (LxWxH): 1240x1080x1680mm
