Max workpiece to be ground: M7135-1:800X350mm, M7135-2:1000X350mm
Max. table longitudinal movement: 880/1020mm
Distance from table to wheel spindle center: 580mm
Max. lateral displacement of the grinding head: 390mm
Grinding head vertical feed per revolution: 4mm
Grinding head vertical feed per grid: 0.02mm
Fast lifting motor
Power: 0.37kw
Speed: 1440rpm
Wheel Size (dia×width×bore): 350x32x127mm
Spindle speed: 1450rpm
Spindle motor: 4/5.5kw
The mechanical surface of the base of parallelis: 300/0.004mm
Surface roughness: Ra:0.63μm
N.W/G.W: 3000/3300kg, 3500/3800kg
Packing size: 2410x2210x2200mm, 2800920180mm
