Distance between centers: 700mm
Swing over bed: 280mm
Swing over cross slide: 170mm
Spindle taper: MT4
Width of bed: 180mm
Spindle bore: 26mm
Range of spindle speeds (variable speed): 50-2500rpm
Range of cross feed: 0.07 -0.40mm /r
Range of longitudinal feed: 0.085-0.832mm/rev
Range of inch threads: 8-56T.P.I
Range of metric threads: 0.2 -3.5mm
Top slide travel: 65mm
Cross slide travel: 180mm
Tailstock quill travel: 75mm
Taper of tailstock quill: MT2
Main motor: 1.1kw
Drilling and milling head: BF20
Spindle taper: MT2
Spindle travel: 52mm
Range of spindle speeds (variable speed): 50-3000rpm
Max.distance from spindle nose to table: 380mm
Max.distance from spindle to columm: 185mm
Motor power: 850w
Packing size (for machine): 137x850x1050mm
Packing size (for stand): 800x580x415mm
N.W: 280kgs
