Distance between centers: 700mm
Swing over bed: 290mm
Swing over cross slide: 165mm
Spindle taper: MT5
Width of bed: 180mm
Spindle bore: 38mm
Range of spindle speeds (variable speed): 80-2000rpm
Range of cross feed: 0.01 -0.10mm /r
Range of longitudinal feed: 0.085-0.832mm/rev
Range of inch threads: 8-56T.P.I
Range of metric threads: 0.2 -3.5mm
Top slide travel: 70mm
Cross slide travel: 160mm
Tailstock quill travel: 70mm
Taper of tailstock quill: MT3
Main motor: 1.5kw
Drilling and milling head: BF20
Spindle taper: MT3
Spindle travel: 52mm
Range of spindle speeds (variable speed): 50-2250rpm
Max.distance from spindle nose to table: 325mm
Max.distance from spindle to columm: 185mm
Motor power: 600w
Packing size (for machine): 1450 × 720 × 1050mm
Packing size (for machine): 800x580x415mm
N.W: 325kgs
