Table size(WxL): 254x508mm
Max.longitudinal travel: 560mm
Cross travel: 275mm
Max.distance from spindle center to table: 450mm
Magnetic chuck size: 250x500mm
Speed of table longitudinal movement: 7-23m/min
Table transerve movement/ Auto feed: 0.1-8mm/min
Table transerve movement/ Repid speed: 990mm/min
Table transerve movement/ Feed of handlwheel: 0.02mm/div.
Wheelhand vertical movement/ Auto feed: -(H/R mode)0.005/0.01/0.02/0.03/0.04/0.05(only for D model)mm/stroke
Wheelhand vertical movement/Rapid speed: -(H mode)610mm/min(only for R model)480mm/min(only for D model)
Wheelhand vertical movement/ Feed of hand-wheel: 0.005mm/div.
Grinding wheel Speed 50HZ: 2850rmp
Grinding wheel Speed 60HZ: 3450rmp
Grinding wheel (ODxWxID) Size: 200x20x31.75mm
Spindle motor: 2.2kw
Hydraulic Motor: 0.75kw
Cooling pump motor: 0.04kw
Elevating motor: -(Hmode)0.25(Rmode)0.5(D mode servo motor)kw
Crossfeed Motor: 0.04kw
Max.loading capacity of table(include magnetic chuck): 180kg
Total rated Power: 3.7kw
Height of machine: 1890mm
Floor space: 2mm/rev
Gross weight: 1640kg
Packing dimensions(LxWxH): 1970x1915x2220mm
