Max.swing over bed: 460mm
Max.swing over cross slide: 170mm
Max.machining length: 350mm
Spindle unit: 170mm
Spindle nose (optional chuck): A2-5/A2-6
Spindle motor power: 5.5kw
Max.spindle speed: 3500rpm
Spindle bore: 56mm
X/Z axis screw specifications: 3210/3210
X-axis travel: 240mm
Z-axis travel: 400mm
X axis motor torque: 7.5N.m
Z axis motor torque: 7.5N.m
X/Z axis repeatability: ±0.003mm
Tool Turret (Optional): 80-8T/12T
Turret center high dimensions: 80mm
Hydraulic Quill dia.: 70mm
Hydraulic Quill traverse: 80mm
Hydraulic Quill taper: MT5
Hydraulic tailstock travel: 200mm
Machine dimension(LxWxH): 2500x1700x1710mm
Net.weight: 2600kg
