Worktable size（LxW）: 650x400mm
T-slot (NxWxD): 3x14x100mm
X/Y/Z axis travel: 500/400/450mm
Distance from spindle center to column: 450mm
Distance from spindle nose to worktable surface: 100-550mm
Spindle taper: BT40
Spindle power: 3.7kw
Max.spindle speed: 10000rpm
Max.feed speed: 10m/min
Rapid feed speed（X/Y/Z): 30/30/25m/min
X/Y/Z axis ball screw: 3210
Max.length of tool: 300mm
Tool change time(T-T):2.5s
Positioning accuracy（X/Y/Z): ±0.005mm
Re-positioning accuracy（X/Y/Z): ±0.002mm
LxWxH: 1900x1700x2240mm
Max.loading of worktable: 300kgs
Machine weight: 3500kg
