X-axis travel: 800mm
Y-axis travel: 500mm
Z-axis travel: 500mm
Spindle nose to table surface: 150-650mm
Spindle center to column surface: 550mm
Table size: 1000×500mm
Max.loading: 500kg
T-slot width: 18mm
T-slot quantity: 5
Spindle taper: BT40
Spindle speed: 8000rpm
Spindle motor: 7.5kw
Max.tool dia: φ80/φ150mm
Max.tool length: 200mm
Max.tool weight: 8kg
X, Y axis rapid feed: 24000mm
Z axis rapid feed: 20000mm
Cutting feed: 1-10000mm/min
Position accuracy: ±0.01mm
Capacity: 15KVA/ 200L
Cooling pump power: 120W
Cooling pump flow: 50L/min
Using air pressure: 0.6MPa
Dimensions: 2750×2300×2300mm
Net weight: 5200Kg
