Worktable size (LxW): 500×1000 mm
T-slot (NxWx D): 5x18x100mm
X/Y/Z axis travel: 850/500/550mm
Distance from spindle center to column: 582mm
Distance from spindle nose to worktable surface: 100-650mm
Spindle taper: BT40
Spindle power: 11/15kw
Max.spindle speed: 8000/10000rpm
Max.feed speed: 12m/min
Rapid feed speed (X/Y/Z): 48/48/32m/min
X/Y/Z axis ball screw: 4016
Tool change time(T-T):2.5s
Positioning accuracy (X/Y/Z): ±0.008m
Re-positioning accuracy (X/Y/Z): ±0.004mm
LxWxH: 2460x2355x2860mm
Max.loading of worktable: 500kgs
Machine weight: 5500kg
