Table size: 2100x500mm
T slot: 4
Size ( Width ): 20mm
Centre distance: 100mm
Max. load of Table: 2000
Longitudinal travel: 1500mm
Cross travel: 670mm
Vertical travel: 670mm
Spindle taper: ISO50 7:24
Spindle speed /step: (60HZ)40-1600rpm/12, (50HZ)35-1345rpm/12
Spindle axis to column surface: 610mm
Spindle nose to table surface: 0-670mm
Longitudinal/cross feed: 20-1800mm / min
Vertical: 10-900mm / min
Longitudinal/cross rapid speed: 3500mm / min
Rapid Traverse vertical: 1750mm / min
Main motor: 7.5kw
Feed motor: 2kw
Elevating motor for headstock: 2kw
Coolant motor: 550w
Package dimension: 2280x2280x2820mm
Overall dimension: 3300x2380x2750mm
N.W/G.W: 7300/8000kg
