Worktable size (LxW): 800x240mm
T-slot (NxWxD): 3x16x60mm
X/Y/Z axis travel: 435/245/530mm
Distance from spindle center to column: 310mm
Distance from spindle nose to worktable: 105-635mm
Spindle taper: BT30
Main motor power: 3.7kw
Max.spindle speed: 6000rpm
Rapid feed speed (X/Y/Z): 10/10/10 m/min
AC servo motor torque (X/Y/Z): 4/4/6N.m
Over size (LxWxH): 1376x1296x1974mm
Net weight: 650kg
