Worktable size (LxW): 1250x360mm
T-slot (NxWxD): 3x18x80mm
X/Y/Z axis travel: 900/350/500mm
Distance from spindle center to column: 460mm
Distance from spindle nose to worktable: 100-600mm
Spindle taper: BT40
Main motor power: 5.5kw
Max.spindle speed: 8000rpm
Rapid feed speed (X/Y/Z): 10/10/8 m/min
AC servo motor torque (X/Y/Z): 7.7/7.7/7.7N.m
Over size (LxWxH): 2220x1850x2350mm
Net weight: 2400kg
