Table size: 1600*360mm
Table Travel (X,Y,Z): 1300mm, 320mm, 400mm
Spindle taper: 7:24 ISO50
Rapid speed of table (X,Y,Z): 1200mm/min, 800mm/min, 600mm/min
Table feed (X,Y,Z): 8 stepsmm/min, X:30-750 \ Y:20-500 \ Z:15–375mm/min
T-slots(NO./Width/Pitch): 3/18/80mm
Spindle speed range: 12 stepsr/min, 60-1800r/min
Distance between spindle nose and table surface: 20-420mm
Arm travel: 500mm
Distance between spindle axis and colomn guide way: 175mm
Main motor: 5.5kw
X,Y,Z to feed Ac servo motor torque: 10N.m
Overall size: 2520*2100*1870mm
Net weight: 2550kg
