Table size: 1370X300mm
Table travel (X/Y/Z): 820/300/400mm
Rapid speed of table (X/Y/Z): 1335/1335/1000mm/min
Spindle taper: Vertical: 3HP: R8 or ISO30; 5HP: ISO40, Horizontal: ISO40
Table feed (X/Y/Z): XY:30-830 Z:23-625mm/min
Distance between horizontal nose and table surface: 75-475mm
Distance between spindle axis and ram surface: 200mm
Spindle speed range: vertical: 1, variable speed 43-3225; 2, step speed 65-4660(16 steps)r/min, horizontal 35-1500 (12steps)
T-slots (No./width/pitch): 3/14/80mm
Arm travel: 450mm
Main motor power: vertical: 3hp / 5hp, horizontal: 3kw
Torque of X/Y/Z axis AC servo motor: 10N.m
Overall size: 1720×1680×2350mm
Net weight: 1650kg
